Model |
LRF XQ50 |
SKU |
76555 |
Microbolometer |
|
Type |
uncooled |
Resolution, pixels |
384x288 |
Pixel Pitch, µm |
17 |
NETD, mK |
< 25 |
Frame refresh rate, Hz |
50 |
Optical Specifications |
|
Lens, mm |
F50 F/1.0 |
Magnification, x |
3-12 |
Eye relief, mm/inch |
50/1.96 |
Field of view (H), °/m@100 |
7.5/13.1 |
Diopter adjustment, D |
-3/+5 |
Detection distance (Object of "deer" type), m/y |
1800/1968.5 |
Aiming Reticle |
|
Click value, mm@100 m – when magnifying, x |
13 mm – 3Ñ…
6.5 mm – 6Ñ…
3.25 mm –12Ñ…
|
Click range, mm@100 m (H/V) |
2600/2600 |
Display |
|
Type |
AMOLED |
Resolution, pixels |
1024Ñ…768 |
Operating Features |
|
Diameter of the riflescope body to assemble the mounting rings, mm |
30 |
Power Supply, V |
3–4.2 |
Battery type / Capacity / Rated Output Voltage |
Li-Ion Battery Pack ÐPS2 / 2000 mAh / DC 3.7 V (removable)
or
Li-Ion Battery Pack APS3 / 3200 mAh / DC 3.7 V (removable)*
Li-Ion Battery Pack APS5 / 4900 mAh / DC 3.7 V (built-in)
|
External Power Supply |
5 V, 9 V (USB Type-C Power Delivery) |
Battery Packs (built-in APS5 and removable APS2) operating time at temp. = 22 °C, hrs** |
10 |
Max. recoil power on rifled weapon, Joules |
6000 |
Max. recoil power on smoothbore weapon, caliber |
12 |
Degree of protection IP code (IEC60529) |
IPX7 |
Operating temperature, °Ð¡ / °F |
-25 – +50 / -13 – +122 |
Dimensions with an eyecup, mm/inch |
420x78.5x94.5 / 16.54x3.09x3.72 |
Weight (without removable battery), kg/oz |
0.97 / 34.22 |
Video Recorder |
|
Photo / video resolution, pixels |
1024x768 |
Video / photo format |
.mp4 / .jpg |
Built-in memory |
16 GB |
Wi-Fi Channel*** |
|
Frequency |
2.4/5 GHz |
Standard |
IEEE 802.11 b/g/n/ac |
Laser Rangefinder |
|
Wavelength, nm |
905 |
Max. Measurement Range, m/y**** |
800 / 874.9 |
Measurement Accuracy, m |
1 |
