Enter the world of thermal vision with the Pulsar Axion thermal imaging monoculars. Our most compact and affordable devices are perfect for those hunters who wish to explore the possibilities of thermal vision without breaking the bank.
Fitting in one hand and light to carry, they still offer high thermal sensitivity and other premium features, including Wi-Fi connectivity and our latest image processing algorithms.
To find out more about the Pulsar Axion thermal imaging monocular price, availability, and suitability for your needs, contact your local distributor.
The Pulsar Axion XG30 Compact is a great tool for close-range observation in areas with thick vegetation.
Main specifications
Sensor
@ 12 µm 640x480
Objective lens
F30/1.2
Magnification, x
2 – 16 (x8 zoom)
FOV (HxV), degrees
14.6 x 9.2
FOV (HxV), m@100m
25.6 x 16.0
Detection range
1300
Sensor
Type
uncooled
Resolution, pixels
640x480
Pixel pitch, µm
12
Sensor NETD, mK
< 40
System NETD, mK
< 25
Frame rate, Hz
50
Optics
Objective lens
F30/1.2
Magnification, x
2 – 16 (x8 zoom)
FOV (HxV), degrees
14.6 x 9.2
FOV (HxV), m@100m
25.6 x 16.0
Eye relief, mm
14
Display
Type
AMOLED
Resolution, pixels
640x400
Range performance
Detection range, m
1300
Video recorder
Video / photo resultion, pixel
960Ñ…600
Video / photo format
.mp4 / .jpg
Build-in memory, GB
64
WI-FI
Wireless protocol
Wi-Fi
Wireless standard
IEEE 802.11 b/g/n/ac (WPA)
Frequency, Ghz
2.4 / 5
Environmental characteristics
Degree of protectionIP code (IEC60529)
IPX7 (waterproof)
Operating temperature range, °Ð¡
-20 - +40
Connections and compatibilities
Mount type
1/4" socket
Supported application
Stream Vision 2
Power supply
Output voltage, V
3.0 – 4.2
Battery type
Li-Ion Battery Pack APS 3
Capacity, mAh
3200
Operating time on battery pack, hat t=22°Ð¡
7
External power supply, V
5 (USB Type C)
Weight & size
Body material
Magnesium alloy
Dimensions, mm
144x41x69
Weight, kg
0,24 (without battery)
