Technical Specifications |
THERMION 3 LRF XR60 |
|
THERMION 3 LRF XT60 |
SKU (without mount) |
76589 |
|
76590 |
Frame rate, Hz |
|
50 |
|
Microbolometer resolution, pixels |
640x480 |
|
1280x1024 |
System NETD, mK |
<18 |
|
<20 |
Pixel pitch, µm |
|
12 |
|
Display type |
|
AMOLED |
|
Display resolution, pixels |
|
2560x2560 |
|
Video & photo recorder |
|
Yes |
|
Built-in memory, GB |
|
128 |
|
USB, type |
|
USB Type-C |
|
Wi-Fi waveband |
|
2.4Ghz / 5Ghz |
|
Bluetooth |
|
Yes |
|
Magnification, x |
4-40 |
|
2–24 |
Objective Lens[AL1.1][AK1.2] |
|
60mm / F1.0 |
|
Field of View, ° (horizontal) |
7.3 |
|
14.6 |
Field of View, m @ 100m |
12.8 |
|
25.7 |
Detection range of thermal imaging channel, m/yd |
|
3100 / 3390 |
|
Click value, mm@100 m |
10 |
|
20 |
Click range, mm@100 m (H/V) |
2000 / 2000 |
|
4000 / 4000 |
Eye relief, mm/inch |
|
65 / 2.6 |
|
Diopter adjustment, dptr. |
|
-5 / +5 |
|
Sensitivity amplification levels |
|
Normal / High / Ultra |
|
Color palettes |
|
9 |
|
Image enhancement |
|
Smoothing filter |
|
Display off |
|
Yes |
|
Automatic Shut-off |
|
Yes |
|
Calibration |
|
Manual / Auto / Semi-auto |
|
Mobile application |
|
Stream Vision 2 / Stream Vision Ballistics |
|
Built-in laser rangefinder |
|
Yes |
|
Laser safety class (BS/EN 60825-1:2014 / EN 50689) |
|
1 |
|
Measurement range, m/yd |
|
1200 / 1312 |
|
Battery type |
|
APS5 |
|
Battery life, hours |
14 |
|
8.5 |
External power |
|
5V / 9V USB Type-C PD |
|
Max. recoil power on rifled weapon, Joules |
|
6000 |
|
Housing material |
|
Aluminum alloy |
|
Operating temperature, °? / °F |
|
-25 – +50 / -13 – 122 |
|
Level of protection |
|
IP67 |
|
Dimensions with an eyecup, mm/inch |
|
391x96x90 / 15.4x3.8x3.5 |
|
Weight (with battery, without mount), kg/oz |
|
1.3 / 45.9 |
|
